OVER 20 YEARS IN SWITCH MANUFACTURING
Piezo, Metal, Pushbutton, Toggle
Slide, Tactile, Rotary, Detector
Piezo, Metal, Pushbutton, Toggle
Slide, Tactile, Rotary, Detector
Variety of contact mechanism, illumination, circuitry, force, mounting, and termination options
Optional spring return for momentary contact
Customization upon request
Industrial control, telecommunication, home appliance, consumer products, instrument, pro-audio…, etc.
| Series | Features | Life Cycle | Rating | Contact Style | Download | Termination | |
|---|---|---|---|---|---|---|---|
|
Series BRM |
Rocker Switch, multiple contact arrangement | 40,000 | 5A@120VAC, (Typical) | SPDT, DPDT, 3PDT, 4PDT |
BRM.pdf |
Vertical & Horizontal, Thru-hole & Solder lug |
|
Series BRA |
Rocker Switch, multiple contact arrangement | 30,000 | 5A@120VAC (Typical) | Lock, Momentary, Combo |
BRA.pdf |
Vertical & Horizontal, Thru-hole & Solder lug |
|
Series SRM |
Variety of actuators, Termination, Mounting, Circuitry Miniature dimension | 30,000 | 120VAC at 3A | Lock Momentary Combo |
SRM.pdf |
Solder lug, Thru-hole, Wire Wrap |
|
Series SRA |
Variety of termination Mounting, Circuitry Miniature dimension IP67 waterproof | 30,000 | 120VAC at 3A | Lock Momentary Combo |
SRA.pdf |
Solder lug, Thru-hole, Wire Wrap |
|
Series SRB |
SP circuitry Miniature dimension IP67 waterproof | 50,000 | 120VAC at 3A | Lock Momentary Combo |
SRB.pdf |
SMD |
|
Series SRU |
Variety of actuators, Termination, Mounting, Circuitry Ultra-miniature size | 40,000 | 20VDC at 0.4A | Lock |
SRU.pdf |
Thru-hole |
|
Series MARA |
Variety of color Mounting, circuitry UL, VDE, CUL, CQC certified | 30,000 | 250VACat 3A | Lock |
MARA.pdf |
Thru-hole |
|
Series RAA |
Variety of color Mounting, circuitry UL, CUL certified Optional LED | 30,000 | 250VAC at 8A | Lock |
RAA.pdf |
Thru-hole |
|
Series RA9 |
Variety of termination Mounting, Circuitry UL, VDE certified Optional LED | 30,000 | 250VAC at 16A | Lock Momentary Combo |
RA9.pdf |
Thru-hole |
|
Series RA4 |
Variety of termination Mounting, Circuitry UL, VDE certified Optional LED | 30,000 | 250VAC at 16A | Lock Momentary Combo |
RA4.pdf |
Thru-hole |
|
Series RA5 |
Variety of termination Mounting, Circuitry UL, VDE certified Optional LED | 30,000 | 250VAC at 16A | Lock Momentary Combo |
RA5.pdf |
Thru-hole |
|
Series RA6 |
SPST Circuitry UL, VDE certified | 30,000 | 250VAC at 4A | Lock Momentary |
RA6.pdf |
Thru-hole |
|
Series RAC |
Rocker Switch, high power rating, liiumination, UL/ VDE | 30,000 | 6A@250VAC (Typical) | Lock |
RAC.pdf |
Vertical, Solder Lug |
