OVER 20 YEARS IN SWITCH MANUFACTURING
Piezo, Metal, Pushbutton, Toggle
Slide, Tactile, Rotary, Detector
Piezo, Metal, Pushbutton, Toggle
Slide, Tactile, Rotary, Detector
Comprehensive offer from miniature to industrial power switch
Variety of contact mechanism, illumination, circuitry, force, mounting, and termination
Momentary or push to lock actuation
Optional waterproof
Customization upon request
Industrial control, telecommunication, home appliance, consumer products, instrument, pro-audio…, etc.
| Series | Features | Life Cycle | Rating | Contact Style | Download | Termination | |
|---|---|---|---|---|---|---|---|
|
Series BPM |
Various mechanism Multiple circuitry Illumination | 50,000 | 3A@120VAC | Momentary Lock |
BPM.pdf |
Solder lug Thru-hole Quick-connect Cable |
|
Series BPA |
Various mechanism Multiple circuitry IP67 waterproof | 50,000 | 3A@120VAC | Momentary |
BPA.pdf |
Solder lug Thru-hole Cable |
|
Series SPM |
Miniature package Various mechanism Multiple circuitry | 50,000 | 3A@120VAC | Momentary |
SPM.pdf |
Solder lug Thru-hole Cable Pin-in-Paste |
|
Series SPA |
Miniature package Various mechanism IP67 waterproof | 50,000 | 3A@120VAC | Momentary |
SPA.pdf |
Solder lug Thru-hole Cable Pin-in-Paste |
|
Series SPB |
Low profile Surface mounting IP67 waterproof | 50,000 | 3A@120VAC | Momentary |
SPB.pdf |
SMD |
|
Series SPU |
Ultraminature Multiple circuitry IP67 waterproof | 40,000 | 0.4VA | Momentary |
SPU.pdf |
Thru-hole |
|
Series HRPS |
Server Power SW Robust mechanism Illumination | 25,000 | 1.0VA | Momentary |
HRPS.pdf |
Thru-hole PIP SMD |
|
Series PAA |
Various Mechanism Long-life Illumination | 500,000 | 0.2A@250VAC | Momentary |
PAA.pdf |
Solder lug Thru-hole Cable |
|
Series PABL |
Illumination Snap-in mounting | 50,000 | 0.1A@30VDC | Momentary |
PABL.pdf |
Solder lug Thru-hole |
|
Series PASD |
Miniature package Illumination | 50,000 | 0.1A@30VDC | Momentary Lock |
PASD.pdf |
Thru-hole |
|
Series PAS |
Variation of caps Multiple mechanism | 10,000 | 1A@125VAC | Momentary Lock |
PAS.pdf |
Solder lug Thru-hole |
|
Series HAB |
Bracket mounted Rright angle | 30,000 | 3A@30VDC | Lock |
HAB.pdf |
Thru-hole |
|
Series LCS |
High power rating UL, VDE certified SPST, DPST circuitry | 30,000 | 15A@250VAC | Momentary Lock |
LCS.pdf |
Solder lug, Quick Connect |
|
Series LCR |
High power rating UL, VDE certified SPST, DPST circuitry | 30,000 | 250VAC at 16A | Momentary Lock |
LCR.pdf |
Solder lug, Quick Connect |
|
Series SP |
Pushbutton switch, side actuation, illumination | 1,000,000 | 24V DC at 12mA | Momentary Lock |
SP.pdf |
Thru-hole |
|
Series SPLS |
Extremely long-life Multiple colors of cap and LED | 5,000,000 | 12VDC at 50mA | Momentary |
SPLS.pdf |
Thru-hole |
|
Series SPLR |
Extremely long-life Multiple colors of cap and LED | 5,000,000 | 12VDC at 50mA | Momentary |
SPLR.pdf |
Thru-hole |
|
Series LPOP |
High power rating SPST, SPDT, DPST | 50,000 | 250VAC at 10A | Momentary Lock |
LPOP.pdf |
Solder lug, Thru-hole |
|
Series WAPM |
Right angle mounted with long travel | 10,000 | 50VDC at 0.3A | Lock |
WAPM.pdf |
Thru-hole |
|
Series KT |
Long-life Optional LED | 500,000 | 50mA@12VDC | Momentary |
KT.pdf |
Thru-hole |
|
Series PAY |
Pushbutton switch Metal button Plastic housing | 100,000 | 0.4VA | Momentary |
PAY.pdf |
Solder lug |
|
Series CK1 |
Key switch for crane control 1 or 2-phase switch Dust proof | 20,000 | 30mA@28VDC | SPST, SPDT |
CK1.pdf |
Thru-hole |
|
Series CK2 |
Key switch for crane control 1 or 2-phase switch Dust proof | 500,000 | 30mA@28VDC | SPST, SPDT |
CK2.pdf |
Thru-hole |
